Name: IEC 61215 B Grade 535W Mono Perc Bifacial Solar Panel
Brand: LEEHO
Price: 1 USD

Brand Name : LEEHO

Model Number : JAM72D30

Certification : IEC61215/IEC61730/TUV/CQC/ISO

Place of Origin : china

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 30000PC

Delivery Time : 5-8working days

Packaging Details : pallet loading

BRAND : JA

GRADE : B

POWER : 535W

STOCK QTY : 3000

Cell Orientation : 144(6X24)

Weight : 31.6

Dimension : 2285±2mmxll 34±2mmx35±1 mm

PACKING : 31pcs per pallet / 155pcs per 20' GP / 620pcs per 40' HC

Contact Now

Ja Brand B Grade Bifacial 535W Stock Mono Perc Mono Solar Panels

Features:

We have the stock solar panel of top 10 tire 1 factories all the year round.

If you interested,please leave contact information. we will send it to you news!

TYPE	JAM72D30 -525/MB	JAM72D30 -530/M B	JAM72D30 -535/MB	JAM72D30 -540/M B	JAM72D30 -545/MB	JAM72D30 -550/MB
Rated Maximum Power(Pmax) [W]	525	530	535	540	545	550
Open Circuit Voltage(Voc) [V]	49.15	49.3	49.45	49.6	49.75	49.9
Maximum Power Voltage(Vmp) [V]	41.15	41.31	41.47	41.64	41.8	41.96
Short Circuit Current(lsc) [A]	13.65	13.72	13.79	13.86	13.93	14
Maximum Power Current(lnnp) [A]	12.76	12.83	12.9	12.97	13.04	13.11
Module Efficiency [%]	20.3	20.5	20.6	20.8	21	21.2
Power Tolerance	0-+5W
Temperature Coefficient of lsc(a_lsc)	+0.045%/°C
Temperature Coefficient of Vbc(3_Voc)	-0.275%/°C
Temperature Coefficient of Pmax(Y_Pmp)	-0.350%/°C
STC	Irradiance 1000W/m2, cell temperature 25°C, AM1.5G

ELECTRICAL CHARACTERISTICS WITH DIFFERENT POWER RANGES (REFRENCE TO 10% SOLAR ILLUMINANCE RATIO)							OPERATING CONDITIONS
TYPE	JAM72D30 -525/MB	JAM72D30 -530/M B	JAM72D30 -535/MB	JAM72D30 -540/M B	JAM72D30 -545/MB	JAM72D30 -550/MB	Maximum System Voltage	1500V DC
Rated Max Power(Pmax) [W]	562	567	572	578	583	589	Operating Temperature	-40°C~+85°C
Open Circuit Voltage(Voc) [V]	49.54	49.67	49.80	49.93	50.03	50.21	Maximum Series Fuse Rating	30A
Max Power Voltage(Vmp) [V]	41.53	41.77	41.99	42.24	42.43	42.67	Maximum Static Load,Front* Maximum Static Load,Back*	5400Pa(112lb/ft²) 2400Pa(50 lb/ft²)
Short Circuit Current(lsc) [A]	14.34	14.39	14.45	14.50	14.56	14.63	NOCT	45±2°C
Max Power Current(lmp) [A]	13.52	13.58	13.63	13.69	13.74	13.79	Bifacial ity**	70%±10%
**Bifaciality=Pmax,rear/Rated Pmax,front							Fire Performance	UL Type 29
